ABB PP845 3BSE042235R1
1. Overview
The ABB PP845 3BSE042235R1 is an operator panel manufactured by ABB, which is widely used in industrial process control, automation systems and human-machine interaction (HMI). Its core functions include digital input/output (I/O), communication interfaces, and human-machine interaction, making it suitable for fields such as industrial automation, building automation, and manufacturing. This product belongs to the ABB Panel 800 series and supports a variety of industrial applications.
2. Parameters
Power Supply and Electrical Characteristics
It adopts 24 VDC power supply, with an input current of 0.3 A, a maximum output current of 2 A, an insulation voltage of 500 VAC, and an insulation resistance of >10 MΩ.
Physical Dimensions and Environment
Dimensions: Approximately 118×45×109 mm
Operating temperature: -25°C to +60°C
Protection class: IP65 or IP20
Communication and Interfaces
It supports communication interfaces such as Ethernet and serial ports (RS422/RS485), as well as a variety of communication protocols.
Other Parameters
Number of input/output channels (e.g., 8 I/O channels)
Communication speed: 10/100 Mbps
3. Product Features
Function and Performance
It offers high reliability and stability, and supports digital input/output, real-time monitoring, alarm functions, data logging, and trend analysis.
Design and Reliability
It adopts a high-resolution display (some models support a 6.5-inch touchscreen), touchscreen operation, and anti-interference design, enabling it to adapt to harsh industrial environments.
Safety and Certification
It complies with CE and RoHS standards and provides a 12-month warranty period.
4. Structure and Composition
Hardware Composition
It features a modular design, including digital input/output channels, communication interfaces, power modules, and control logic circuits.
Interfaces and Connections
It supports a variety of communication interfaces (such as Ethernet and serial ports), power input interfaces, and external device connection interfaces.
5. Application Fields
Industrial Automation
It is widely used in manufacturing, energy, water treatment, building automation, chemical industry, power systems, and other sectors.
Specific Scenarios
It is applied in process control, equipment monitoring, human-machine interaction, and remote monitoring and management.
6. Installation and Maintenance
Installation
The installation process is simple. It can be configured through ABB engineering software and supports modular installation and integration.
Maintenance
It provides remote monitoring and fault diagnosis functions. Regular maintenance is recommended to ensure long-term stable operation.
