ABB CI854AK01 3BSE030220R1
The ABB CI854AK01 3BSE030220R1 is a high-performance industrial controller module, specifically designed for industrial automation and process control applications. Equipped with powerful processing capabilities, support for multiple communication protocols, and a rich set of features, this module is widely used in various industries such as power, chemical, water treatment, and papermaking. As an integral part of the ABB AC 800M I/O system, the CI854AK01 3BSE030220R1 provides reliable automation control solutions, ensuring efficient operation and stability of industrial processes.
Parameters
Dimensions: 110 mm x 60 mm x 25 mm
Weight: 200 g
Operating Temperature: -20°C to +60°C
Storage Temperature: -40°C to +85°C
Protection Class: IP20
Input Range: -10 V to +10 V
Resolution: 12 bits
Sampling Rate: Up to 1 kHz
Accuracy: 0.1%FS
Noise: <0.2 mVrms
Communication Protocols: Supports multiple protocols including Modbus, Profinet, and PROFIBUS DP
Power Supply: 24 VDC
Power Consumption: 5 W
Product Features
High Reliability: Adopts high-quality materials and advanced manufacturing processes to ensure stable operation in harsh industrial environments.
High-Speed Processing Capability: Features a powerful processor that responds quickly to control commands and data acquisition requirements, making it suitable for real-time control applications.
Rich Communication Interfaces: Supports multiple communication protocols, facilitating data exchange and integration with other devices and systems.
Easy Configuration and Operation: Offers a user-friendly interface and simple setup process for quick configuration and operation.
Self-Diagnosis and Protection Functions: Equipped with fault detection and alarm functions to take timely measures for protecting the system and equipment, reducing downtime.
Hot-Swappable Support: The module supports hot-swapping, allowing maintenance and replacement without shutting down the system, thus improving system availability.
Fault-Tolerant Operation: Optional fault-tolerant function enhances system reliability and continuous operation capability through redundant design.
Structure and Composition
Modular Design: Based on rail mounting, enabling easy installation, maintenance, and expansion.
Main Components: Includes communication interfaces, processor units, input/output interfaces, and power modules.
Interface Types: Equipped with multiple communication ports and analog input channels, supporting connections to various sensors and actuators.
Material: The housing is made of ABS plastic, which provides excellent mechanical strength and protective performance.
Application Fields
Industrial Automation: Used for monitoring and controlling production lines, factory equipment, and processes to improve production efficiency and product quality.
Process Control: In industries such as chemical, oil and gas, and power, it controls key parameters like temperature, pressure, and flow.
Water Treatment: Applied in water treatment plants to monitor and regulate water quality treatment processes.
Papermaking and Textile: Controls the tension of paper and textile materials to ensure material stability during production.
Food and Beverage: Implements automated control on production lines to ensure food safety and production efficiency.
Transportation Systems: Used for traffic signal control, tunnel equipment, and elevator control to enhance the intelligence of traffic management.
Installation and Maintenance
Installation Steps
a. Mount the module on the DIN rail to ensure stability and reliability.
b. Connect the PROFIBUS DP cable to the module’s communication port, ensuring a secure connection.
c. Configure the module to the required communication mode (master or slave) and connect it to the AC 800M controller.
Maintenance Requirements
Regularly check the module’s connections and operating status to ensure no looseness or damage.
Utilize the module’s self-diagnosis function to detect and address potential faults in a timely manner.
When module replacement or maintenance is needed, use the hot-swapping function for quick operations to reduce system downtime.
