ABB AIM0006 2RCA021397A0001F
ABB AIM0006 2RCA021397A0001F is an analog input module under the ABB Advant Controller 200 Series, specifically designed for industrial process control and data acquisition systems. This module delivers high-precision signal conversion capabilities, used to connect various sensors (such as temperature transmitters, pressure sensors, flow meters, etc.), converting analog signals (4-20mA, 0-10V, etc.) into digital signals for processing by the control system.
Core Values of AIM0006
High-Precision Signal Acquisition: Offers a measurement accuracy of ±0.1% FS, ensuring accurate monitoring of process parameters.
Modular Design: Supports hot swapping (when permitted by the system), facilitating maintenance and expansion.
Industrial-Grade Reliability: Features strong anti-interference capabilities, suitable for harsh industrial environments.
Product Specifications
Product Model: ABB AIM0006 2RCA021397A0001F
Manufacturer: ABB
Product Type: Analog Input Module
Number of Input Channels: 8 channels (configurable)
Input Signal Types: 4-20mA, 0-10V DC, Thermocouple (TC), RTD (PT100)
Measurement Accuracy: ±0.1% FS (for 4-20mA/0-10V), ±0.5°C (for RTD)
Resolution: 16-bit (0.0015% FS)
Isolation Voltage: 500V AC (between channels and between channels and system)
Sampling Rate: 10ms per channel (typical)
Operating Temperature Range: -20°C to +70°C (-4°F to +158°F)
Protection Class: IP20 (must be installed in a control cabinet)
Mounting Method: DIN Rail or rack mounting
Communication Interface: Communicates via the Advant Controller 200 backplane bus
Power Supply Voltage: 24V DC (powered by the backplane)
Power Consumption: ≤5W (typical)
Structure and Composition
AIM0006 adopts a modular industrial design, with main components including:
Signal Conditioning Circuit: Independent amplifier and filter for each channel, supporting multiple signal types (configured via jumpers or software).
A/D Converter: 16-bit high-precision ADC, ensuring distortion-free signal digitization.
Isolation Barrier: Optocoupler or magnetic isolation technology to block ground loop interference.
Backplane Interface: Interacts with the Advant Controller 200 backplane via a high-speed connector.
Status Indicators: LED per channel to display signal status (normal/overrange/wire break).
Metal Enclosure: Provides EMI shielding and mechanical protection.
Key Features and Advantages
High Precision and Multifunctional Input
Supports mixed connection of 4-20mA, 0-10V, RTD, and thermocouple signals, reducing the need for multiple module types.
Features ±0.1% FS accuracy and 16-bit resolution, meeting the requirements of precision process control.
Anti-Interference and Reliability
Equipped with 500V AC isolation and EMC filtering to suppress electromagnetic noise in factory environments.
Built-in sensor wire break detection for real-time alarming of abnormal signals.
Seamless System Integration
Natively compatible with the ABB Advant Controller 200 Series (e.g., AC210).
Enables quick configuration of channel parameters via Composer engineering software.
Industrial-Grade Durability
Operates in a wide temperature range (-20°C to +70°C) and withstands vibration of 5g @ 100Hz.
Complies with IEC 61131-2 and UL 508 standards.
Application Fields
AIM0006 is suitable for the following scenarios:
Process Industry: Temperature/pressure monitoring of chemical reactors (RTD + 4-20mA); signal acquisition of oil pipeline flow meters.
Power Industry: Interface for boiler drum water level transmitters.
Water Treatment: Data conversion for pH value and turbidity sensors.
Typical Application Case
In an oil refinery, AIM0006 collects signals from 8 channels of 4-20mA pressure transmitters, and realizes pump group interlock control through the Advant Controller 200.
Installation and Maintenance
Installation Key Points
Perform operations with power off (or confirm the system supports hot swapping).
Use shielded twisted-pair cables for signal lines, with the shield layer grounded at one end (control cabinet side).
Set the input type via jumpers (e.g., voltage/current mode).
Maintenance Recommendations
Regularly calibrate the zero point/full scale (recommended once a year).
Check the tightness of terminals to prevent poor contact.
