Switzerland The ABB TC630 features a durable die-cast aluminum housing and an industrial plastic front panel, ensuring excellent heat dissipation and mechanical strength. Its structure is divided into two main parts: the front panel integrates a high-brightness 12.1-inch TFT display, covered with a scratch-resistant resistive touch layer, and the surrounding seal meets IP65 protection standards to resist dust and water ingress.
At the core of the device’s interior is a highly integrated mainboard, which houses a high-performance RISC processor, operating memory (RAM), and storage Flash. The mainboard also integrates multiple communication controllers that manage the Ethernet port, multiple serial communication ports, and the expandable CF card interface. All these components are compactly arranged within the metal housing and connect to external power supplies, networks, and devices via multiple cable interfaces at the rear. The design fully considers Electromagnetic Compatibility (EMC), ensuring stable operation in harsh electrical environments.
The ABB TC630 offers a bright display with SVGA resolution, ensuring clear visibility even in strong light conditions. Its resistive touchscreen supports glove operation, making it ideal for industrial environments. Combined with ABB’s Panel Builder 600 configuration software, users can create dynamic, intuitive, and information-rich graphical interfaces—greatly simplifying the operator’s monitoring and intervention processes.
Equipped with a rich set of communication interfaces, this device serves as a central connectivity hub. Its integrated Ethernet and multiple serial ports support nearly all mainstream industrial protocols, allowing seamless integration into the ABB AC500 PLC system or use as a universal HMI connected to third-party PLCs (e.g., Siemens, Schneider). This provides significant flexibility in system design.
Designed specifically for harsh environments, the TC630’s front panel meets IP65 protection standards, resisting dust, oil, and liquid splashes on production sites. Its wide-range DC power input (19.2-28.8 VDC) adapts to common voltage fluctuations. With wide-temperature operation capability and strong resistance to vibration and electromagnetic interference, the device ensures reliable 24/7 continuous operation, minimizing downtime.
The ABB TC630 is widely used in industrial fields requiring reliable monitoring and operation. In process industries (e.g., chemicals, pharmaceuticals, and water treatment), it is used to display process flow diagrams, trend curves, and alarm lists, as well as to operate valves, pumps, and other equipment. In discrete manufacturing (e.g., automotive production lines, packaging machinery, and material handling systems), it monitors equipment status, displays production data, sets parameters, and diagnoses faults.
Additionally, in sectors such as energy, maritime, and infrastructure, the TC630 acts as a key HMI interface, providing operators with all the information and tools needed to control complex automated systems. It effectively addresses core challenges such as unclear equipment status, cumbersome operations, and difficult fault troubleshooting.
Before installing the ABB TC630, accurately machine mounting holes in the panel according to the provided cutout dimensions. Ensure the installation environment meets temperature and humidity requirements and is away from strong electromagnetic interference sources. Verify that the 24VDC power supply is stable and within the rated range, and prepare all communication cables.
Daily maintenance primarily involves keeping the front panel clean—use a soft, damp cloth for wiping and avoid corrosive chemicals. Regularly check that all communication interface connections are secure. Back up project files via the CF card or network. If the device runs slowly or freezes, restart it using the reset hole at the rear. For system-level maintenance, update the operating system or applications via the CF card. After long-term use, check the voltage of the backup battery (if equipped) to prevent project data loss.
Xingruijia focuses on providing ABB industrial automation full range product services and your intelligent control solution partner
If you would like to learn more about our products and services, please feel free to contact us at any time!
Sales Manager : Jinny
Email : sales1@xrjdcs.com
Whatsapp/Mobile:+86 15359273791
