ABB REM543BM215AAAB
1. Overview
The REM543BM215AAAB serves as the core computing unit of the ABB REX543 series multifunctional digital protection relays. It adopts a high-performance 32-bit DSP + FPGA architecture, specifically designed for medium-voltage (MV) distribution networks (10 ~ 35 kV). Compliant with the IEC 60255 standard and holding a SIL 2 safety rating, this unit enables multiple power system protection functions and supports remote monitoring and control via various communication interfaces.
2. Main Parameters
Processor: High-performance 32-bit DSP + FPGA
Protection Functions: Multiple protection types including overcurrent, grounding, differential, distance, voltage, and frequency protection
Communication Interfaces: RS-485, Ethernet (supports IEC 61850)
Operating Voltage: 220 V AC (typical value)
Operating Temperature: –25 °C ~ +70 °C
Compliant Standards: IEC 60255, SIL 2
Applicable Voltage Level: 10 kV ~ 35 kV distribution systems
Physical Dimensions: Standard 19-inch rack (refer to the product manual for specific dimensions)
Protection Class: IP20 (for internal rack installation)
3. Product Features
High Reliability: Adopts a dual-redundant DSP + FPGA structure, with self-test and fault transfer capabilities.
Multifunctional Protection: A single configuration supports multiple protection algorithms, meeting the needs of various scenarios such as distribution networks, transformers, generators, and motors.
Flexible Communication: Supports IEC 61850-GSE, MMS, as well as traditional Modbus/Profibus protocols, facilitating integration with SCADA and EMS systems.
Modular Design: Can be freely combined with other modules in the REX543 series (input/output, communication, display), enabling easy system expansion.
Compliance with Safety Standards: Certified with SIL 2, meeting the safety integrity requirements of power systems.
4. Structure and Composition
Main Control Board: Integrates DSP + FPGA processors, memory, and clock modules.
Power Supply Module: Equipped with an internal power converter, providing 24 V DC for internal circuits.
Communication Interface Board: Features RS-485 and Ethernet ports (with optional IEC 61850 adapter).
I/O Interfaces: Includes terminal blocks for digital/analog inputs and digital outputs, supporting external sensors and actuators.
Rack Mounting Bracket: Complies with standard 19-inch rack dimensions, enabling easy installation in power distribution cabinets.
5. Application Fields
Fault protection and automatic reclosing for medium-voltage (10 ~ 35 kV) distribution networks
Transformer protection (overcurrent, overload, differential protection)
Generator sets (over/under-voltage, frequency protection)
Large motors (overload, grounding protection)
Industry and infrastructure (petrochemicals, rail transit, port power distribution)
6. Key Points for Installation and Maintenance
On-Site Inspection: Verify cabinet dimensions, ventilation conditions, and grounding reliability.
Mechanical Installation: Slide the module into the 19-inch rack and secure it with screws; ensure terminal blocks are aligned.
Power Wiring: Connect the 24 V DC power supply according to the wiring diagram, and check polarity and fuses.
Signal Wiring: Connect sensors such as Current Transformers (CT) and Voltage Transformers (VT) based on protection requirements.
Communication Cabling: Connect RS-485 or Ethernet ports, and configure IP addresses and IEC 61850 parameters.
Software Configuration: Use ABB’s configuration tools (e.g., Power System Analyzer) to download protection logic and set parameters.
Function Testing: Conduct on-site simulation tests (e.g., overcurrent, grounding) to verify relay operation and signal transmission.
Regular Maintenance: Every 6 ~ 12 months, check the tightness of wiring, clean heat sinks, update firmware, and record operation logs.
