1. Overview
Product Positioning: It is a high-voltage and low-voltage hybrid fuse, suitable for short-circuit protection in power distribution networks, substations, and large-scale industrial installations.
Technical Standards: Complies with IEC 60269‑1/2, UL 248‑8 (Class J), as well as ABB's proprietary safety and reliability certifications.
2. Main Technical Parameters
Rated Voltage: 1000 V DC / 690 V AC
Rated Current: 320 A (the "320" in the model indicates the rated current)
Breaking Capacity: 10 kA (for instantaneous short circuits)
Dimensions: 10 × 38 mm (standard Mini‑FPR specification)
Enclosure Protection Rating: IP20 (dust-proof and drip-proof)
Operating Temperature Range: –25 °C ~ +85 °C
Service Life: Approximately 20 years (maintenance-free service life)
3. Product Features
Fast Fusing: Adopts high-performance fuse element material to achieve high-current interruption within 0.1 s.
Low Residual Voltage: After fusing, the residual voltage is ≤ 10 V, ensuring the safety of downstream equipment.
Modular Structure: Can be directly mounted on standard DIN rails or bus ducts, facilitating on-site replacement.
High Reliability: Features moisture-proof and dust-proof design, suitable for harsh industrial environments.
Easy Detection: The enclosure is transparent or equipped with an indicator light, enabling quick identification of whether the fuse is blown.
4. Structure and Composition
Enclosure: High-strength polymer or metal enclosure, providing mechanical protection.
Fuse Element Assembly: Removable fuse element cartridge, filled with high-conductivity alloy wire inside.
Terminals: Screw-type or spring-type terminals, compatible with wires of 0.5 mm²-6 mm².
Indicator Device: Fusing indicator light or color mark, facilitating quick on-site judgment.
5. Typical Application Fields
Power Distribution: Protection for the low-voltage side of substations, power distribution cabinets, and busbars.
Industrial Automation: Front-end protection for large motors, frequency converters, and servo systems.
Building Facilities: Protection for critical loads such as building power distribution, UPS, and fire pumps.
Transportation Facilities: Short-circuit protection for rail transit and airport power supply systems.
6. Installation Key Points
Confirm Voltage and Current: Ensure that the selected model matches the rated voltage and current of the system.
Wiring Method: Use screw or spring terminals; wire connection must be done after power is cut off, and ensure the wire cross-sectional area complies with specifications.
Fixing Method: Can be directly clipped into DIN rails or fixed in bus ducts using bolts.
Check Polarity: For DC systems, the positive and negative wiring directions must be confirmed.
On-Site Testing: After power is turned on, check the indicator light or use a multimeter to confirm no leakage current.
7. Maintenance and Overhaul
Regular Inspection: Inspect the integrity of the enclosure, the tightness of terminals, and the status of indicator lights every 6 months.
Fuse Element Replacement: After fusing, replace the entire fuse element assembly directly without disassembling the enclosure.
Cleaning: Use a dry soft cloth to remove dust; do not use corrosive cleaning agents.
Recording: Record the time, cause, and on-site current value after each replacement or overhaul to facilitate subsequent trend analysis.
