ABB SDCS-CON-4-COAT 3ADT313900R1001
The SDCS‑CON‑4 COAT is a high-performance control board developed by ABB for its Safety Drive Control Systems (SDCS). It features a protective coating (COAT) to enhance corrosion resistance and dustproof capabilities. Integrating a local CPU, this board enables I/O, communication, and function expansion through pluggable sub-modules, making it suitable for precision motor control and safety protection in industrial automation scenarios.
Key Specifications
Model: SDCS‑CON‑4 COAT 3ADT313900R1001
Power Supply: 24 V DC (48 V optional)
Operating Temperature: –2 °C ~ +55 °C (the protective coating allows adaptation to harsher environments)
Dimensions: 180 mm × 120 mm × 30 mm (compatible with standard DIN‑Rail mounting)
Weight: ≈ 1 kg
Interfaces: Multiple digital I/O, analog inputs, and fieldbuses (including PROFIBUS, EtherNet/IP, etc.)
Compatibility: Compatible with ABB 3ADT series drives and SDCS‑CON‑4 series sub-modules
Certifications: CE, RoHS, and ISO 9001 (manufacturing compliance)
Product Features
Protective Coating (COAT): A dedicated anti-corrosion and dustproof coating that suits environments with high humidity, dust, or chemical corrosion.
Modular Design: Supports various I/O, communication, and functional sub-modules, allowing flexible configuration of system functions.
High Reliability: Equipped with a redundant CPU and self-test function, meeting the requirements of Safety Integrity Level (SIL 2/3).
Easy Maintenance: Adopts a pluggable modular structure, enabling on-site replacement or upgrade without shutdown.
Strong Compatibility: Seamlessly integrates with ABB’s existing SDCS‑CON‑4 series control systems.
Structure and Composition
Motherboard (CPU): Provides real-time control computing and system management.
Sub-module Slots: Used for installing I/O, communication, and function expansion modules (e.g., analog input, digital output, PROFIBUS, EtherNet/IP, etc.).
Power Module: Incorporates an internal DC-DC converter to ensure stable voltage supply.
Protective Enclosure: A metal housing with a protective coating, meeting an ingress protection rating of IP 54 or higher.
Connection Terminals: Features standard DIN‑Rail mounting holes and terminal blocks for easy on-site wiring.
Typical Application Fields
Automated production lines in the manufacturing industry
Material handling systems (conveying, stacking)
Power plants and power distribution automation
Oil and natural gas production and transportation
Rail transit and vehicle drive control
Any industrial scenario requiring high-reliability safety drives
Installation and Maintenance Guidelines
Installation
Fix the board using the DIN‑Rail method, ensure horizontal installation, and use anti-loosening bolts.
Check the polarity when connecting the power cord, and use junction boxes that comply with the IEC 60204 standard.
Insert the corresponding sub-modules according to system requirements, and ensure the card slots are locked securely.
Wiring
Arrange I/O and communication cables in accordance with the wiring diagram provided by ABB to avoid cross-interference.
For fieldbuses, use shielded cables and add terminal resistors at the terminals.
Commissioning
After power-on, perform a self-test using ABB’s on-site commissioning software (e.g., 800xA, System 800xA) to confirm that all modules are in normal status.
Configure safety parameters (safety level, redundant path) and conduct functional tests.
Maintenance
Regularly check the integrity of the protective coating; clean or re-spray it if necessary.
Visually inspect pluggable sub-modules to ensure no dust, corrosion, or looseness.
Record operation logs and conduct preventive maintenance every 12 months in accordance with ABB’s maintenance manual.
