ABB 1TGB302004R5003_Xiamen XingRuiJia Import and Export CO,LTD

Model：ABB 1TGB302004R5003

Brand: ABB
Price range (USD): 100-20000
Country: Switzerland
Parameter: Power Supply Voltage: 24 V DC or 48 V DC
Power Consumption: < 5 W
Communication Protocols: Modbus TCP/IP, BACnet/IP
Communication Rate: 10/100 Mbps
Interface: 1 RJ45 Ethernet port
Dimensions: Approximately 120 mm × 80 mm × 35 mm
Weight: Approximately 250 g
Operating Temperature: ‑20 °C ~ 55 °C
Storage Temperature: ‑40 °C ~ 85 °C
Relative Humidity: 0 % ~ 95 % (non-condensing)

ABB 1TGB302004R5003

The 1TGB302004R5003 is a relay protection device designed by ABB specifically for power systems. Its primary function is to detect faults such as overcurrent, short circuits, and ground faults, then quickly respond by sending protection signals or executing circuit-breaking operations. This ensures the prevention of equipment damage and maintains the stable operation of the power system.

Main Technical Parameters

Power Supply Voltage: 24 V DC or 48 V DC
Power Consumption: < 5 W
Communication Protocols: Modbus TCP/IP, BACnet/IP
Communication Rate: 10/100 Mbps
Interface: 1 RJ45 Ethernet port
Dimensions: Approximately 120 mm × 80 mm × 35 mm
Weight: Approximately 250 g
Operating Temperature: ‑20 °C ~ 55 °C
Storage Temperature: ‑40 °C ~ 85 °C
Relative Humidity: 0 % ~ 95 % (non-condensing)

Product Features

Fast Response: It can detect faults and send protection signals instantly when a fault occurs, significantly shortening the fault duration.
Multi-Protocol Compatibility: It supports both Modbus TCP/IP and BACnet/IP simultaneously, facilitating integration with systems from different manufacturers.
Low-Power Design: With power consumption below 5 W, it is suitable for on-site environments with energy efficiency requirements.
Compact and Reliable: Featuring a small size and light weight, its housing meets industrial protection standards, enabling it to adapt to harsh working environments.

Structure and Composition

Main Unit Module: Equipped with core protection logic and communication chips.
Power Supply Module: Provides stable 24 V/48 V DC power.
Communication Interface: An RJ45 Ethernet port that supports dual protocols.
Input/Output Terminals: Used for connecting current sensors, voltage sensors, and relay outputs.
Enclosure: Made of metal or high-strength plastic, with dustproof and waterproof properties.

Typical Application Fields

Protection for main and backup power supplies in power plants and substations
Protection for distribution network lines, transformers, and busbars
Comprehensive protection for power distribution systems in industrial parks and buildings
Smart grid projects requiring remote monitoring and automated control

Installation and Maintenance Points

Installation Location: It should be placed in a cabinet or dedicated protective box with good ventilation, no strong magnetic fields, and no direct exposure to high temperatures.
Wiring Specifications: Follow the ABB standard wiring diagram to ensure correct connection between current sensors, voltage sensors, and the protection relay, avoiding incorrect wiring.
Communication Configuration: Configure the IP address, subnet mask, and gateway in the on-site network to ensure normal Modbus/BACnet communication.
Regular Inspection: Conduct inspections every 6 months to check the integrity of the enclosure, the tightness of wiring, and the stability of power supply. Update the firmware if necessary to obtain the latest protection algorithms.
Fault Diagnosis: Use the built-in self-test function and remote monitoring platform to view fault logs, quickly locate and resolve abnormalities.
