ABB V17152310 Power Supply Module

Overview

The ABB V17152310 is a high-performance power supply module designed to provide stable and reliable DC power for ABB’s industrial automation and control systems. It is commonly used in AC 800M, Advant, and other ABB distributed control systems (DCS), ensuring continuous power delivery to processors, I/O modules, and communication interfaces.

Built with ABB’s advanced design standards, the V17152310 offers excellent protection against voltage fluctuations, electrical noise, and overloads—making it suitable for use in demanding industrial environments where precision and uptime are critical.

Main Features

High Efficiency: Converts AC input to stable, regulated DC output with minimal power loss.

Wide Input Voltage Range: Supports universal AC input for flexibility in global installations.

Overload & Short-Circuit Protection: Ensures system safety and equipment longevity.

Compact Modular Design: Fits seamlessly into ABB control system enclosures.

LED Status Indicators: Provide real-time operational and fault status.

Low Ripple Output: Maintains signal stability for sensitive electronic components.

Long Service Life: Designed for continuous 24/7 operation in harsh environments.

Technical Parameters

Structure & Composition

The ABB V17152310 is built around a high-efficiency switching converter topology that ensures minimal energy loss and heat generation. The internal architecture includes:

Input Rectifier and Filter Circuit: Converts AC to DC while suppressing harmonics and transients.

Switching Converter Stage: Regulates voltage with fast transient response.

Output Regulation Circuit: Maintains precise voltage levels under varying loads.

Protection Module: Provides automatic shutdown in case of overload, short circuit, or thermal fault.

Status LEDs: Indicate input power, output status, and fault conditions for easy diagnostics.

Its rugged aluminum casing offers electromagnetic shielding and mechanical protection, making it ideal for industrial control panels.

Applications

The V17152310 Power Supply Module is widely used in industrial and automation systems where consistent and clean DC power is essential, including:

Process Automation Systems

PLC and DCS Controllers (AC 800M, Advant)

Factory and Machine Control Cabinets

Power Generation and Distribution Panels

Oil & Gas Control Systems

Marine and Transportation Automation

Its robust design ensures optimal operation even under fluctuating input power or harsh environmental conditions.

Installation & Maintenance

Installation Steps:

Mount the module on a DIN rail or a flat panel surface.

Connect AC input lines according to ABB’s wiring diagram.

Wire the DC output to the corresponding control system terminals.

Verify polarity and grounding before powering on.

Observe LED indicators to confirm normal operation.

Maintenance Tips:

Ensure adequate ventilation for heat dissipation.

Periodically check wiring connections and output voltage levels.

Clean the module using dry compressed air; avoid solvents or liquids.

Replace only with identical ABB-certified modules to maintain system integrity.

Additional Information

The ABB V17152310 complies with international industrial standards (IEC, UL, CE) for safety, EMC, and environmental performance. Each unit undergoes factory testing to ensure electrical stability, thermal endurance, and protection reliability.

With its robust design, compact size, and advanced protection features, the V17152310 guarantees consistent power delivery, making it a trusted component for mission-critical ABB automation systems.
