ABB REM615 Protection Relay Front Panel

Product Introduction

The ABB REM615 Panel is a front interface panel designed for the ABB REM615 motor and feeder protection relay. It provides a clear, user-friendly human–machine interface (HMI) for monitoring, control, configuration, and diagnostics of electrical protection systems. The panel plays a critical role in daily operation by allowing operators to interact directly with the relay without external tools.

Engineered for reliability and clarity, the REM615 panel is suitable for both industrial and utility-grade electrical installations.

Functional Overview

The REM615 front panel enables operators to:

View real-time operating data and protection status

Access alarms, events, and fault records

Perform local control operations (start/stop, acknowledge alarms)

Navigate relay settings and configuration menus

Monitor system health through visual indicators

Its intuitive layout helps reduce operator errors and improves response time during abnormal conditions.

Panel Characteristics and Parameters

The ABB REM615 panel is equipped with a high-contrast display that ensures excellent readability in various lighting conditions. It includes function keys and navigation buttons designed for frequent industrial use. Visual LED indicators provide immediate feedback on relay status, alarms, and trip events. The panel is designed for front mounting and integrates seamlessly with the REM615 relay housing.

Design and Structure

Structurally, the REM615 panel consists of:

A robust front housing suitable for switchgear environments

An LCD display for data visualization and menu navigation

Dedicated push-buttons for control and navigation

LED indicators for status, alarms, and protection trips

The panel design prioritizes durability, ease of cleaning, and long-term operational stability.

Typical Application Scenarios

The ABB REM615 panel is commonly used in:

Motor protection and control systems

Industrial feeder protection panels

Medium-voltage and low-voltage switchgear

Manufacturing plants and process industries

Power distribution systems in utilities and infrastructure projects

Installation and Maintenance

Installation is performed from the front side of the switchgear, allowing easy access during commissioning or replacement. The panel requires minimal maintenance, mainly involving periodic visual inspection and functional checks of buttons and display clarity. Its design supports long service life even in demanding industrial environments.

Operational Advantages

Improves operator interaction with protection relays

Enhances visibility of system status and fault information

Supports faster troubleshooting and reduced downtime

Fully compatible with ABB REM615 relay standards

Designed to meet industrial electrical safety requirements
