ABB CI854AK01-3BSE030220R1

ABB CI854AK01-3BSE030220R1 is an industrial automation communication module specifically designed for the PROFIBUS-DP/V1 fieldbus, widely applied in industrial control systems. Belonging to the ABB AC 800M series, this module supports efficient communication with PROFIBUS DP networks, featuring high reliability, multi-protocol compatibility, and a modular design, making it suitable for harsh industrial environments.

Parameters

Interface Type: PROFIBUS-DP/V1

Communication Speed: Up to 12 Mbit/s (some materials mention 12 Mbps, with consistent meaning despite unit differences).

Dimensions: 127.5 mm (depth) × 59 mm (width) × 186 mm (height).

Weight: Approximately 0.2 kg (some materials mention 0.5 kg or 0.7 kg, possibly varying by version or configuration).

Power Voltage: 24V DC.

Operating Temperature Range: -20°C to +60°C (some materials mention -40°C to +70°C, subject to the latest data).

Protection Level: IP65 (some materials mention IP20, possibly varying by application scenario).

Product Features

High Reliability: Utilizes high-quality materials and advanced processes to ensure stable operation in harsh environments.

Multi-Protocol Support: Compatible with protocols such as PROFIBUS DP, Modbus RTU, and IEC 60870-5-101 for flexible communication.

Redundancy Design: Supports PROFIBUS DP master redundancy to enhance system reliability.

Modular Design: Facilitates installation, maintenance, and expansion, supporting DIN rail mounting.

Protection Level: IP65 or IP20 (depending on the specific model and application scenario).

Structure and Composition

Core Components:

Communication Interface Module: Responsible for PROFIBUS DP data transmission.

Base Plate (TP854): Provides electrical connections and mechanical support.

Microprocessor: Processes data and executes control logic.

Power Circuit: Supplies power to the module.

Heat Sink: Ensures stable operation under high loads.

Housing: Made of aluminum alloy to provide physical protection.

Application Areas

Industrial Automation: Used in process control, machine automation, building automation, etc.

Power Systems: Monitoring and management of power plants, substations, and distribution stations.

Manufacturing: Equipment communication in industries such as automotive manufacturing, food processing, and textiles.

Energy Industry: Tension control in petrochemical, metallurgy, papermaking, and other fields.

Transportation: Control systems for trains, ships, and aircraft.

Installation and Maintenance

Installation:

Typically mounted on a DIN rail and connected to the ABB AC 800M system or other PROFIBUS DP devices.

Ensure the installation environment meets the protection level requirements (IP65 or IP20).

Maintenance:

Regularly check whether cable connections are secure to avoid looseness or wear.

Clean the module surface to prevent dust or oil from affecting heat dissipation.

Calibrate sensors or actuators to ensure data accuracy.

Avoid mechanical impact or vibration to extend service life.
