ABB SUE3000 1VCR007346 G0032

ABB SUE3000 1VCR007346 G0032 is a high-performance industrial Human-Machine Interface (HMI) controller designed for industrial automation. With a modular structure and high reliability, it suits various industrial scenarios. Its core function is to realize real-time monitoring of industrial equipment, parameter configuration, and control logic execution through a graphical interface, widely applied in fields like process control, discrete control, and building automation.

Display

Size: 7-inch color TFT LCD with a resolution of 800 x 480 pixels.

Touchscreen type: Resistive.

Communication Interfaces

Support RS232C, RS485, Ethernet, and protocols like Modbus and Profibus.

Input/Output

Digital input/output: 16 channels each; analog input/output: 2 channels each.

Protection Level

IP65, suitable for harsh industrial environments.

Operating Temperature

-20°C to +60°C.

Dimensions and Weight

Dimensions: 230 mm x 160 mm x 60 mm; weight: 1.5 kg.

Product Features

Modular Design

Supports flexible expansion for easy maintenance and upgrading.

High Reliability

Redundant design and fault diagnosis functions ensure long-term stable operation.

Multi-language Support

Provides multi-language interfaces including Chinese to simplify operation.

Built-in PLC Function

Can directly control equipment without an additional controller (PLC = Programmable Logic Controller).

Data Recording and Analysis

Supports historical data recording for convenient fault diagnosis and trend analysis.

Structure and Composition

Hardware Composition

Display: 7-inch color TFT LCD touchscreen.

Input/output ports: 16 digital inputs/outputs, 2 analog inputs/outputs.

Communication interfaces: RS232C, RS485, Ethernet.

Control buttons and indicators: 7 control buttons, 8 LED indicators (including lock status indication).

Software Functions

Programming software: Provides intuitive programming tools supporting logic configuration.

HMI interface: Single-line diagram display, menu navigation, real-time parameter monitoring.

Application Fields

Industrial Automation

Process control: Parameter monitoring in industries such as chemical, oil & gas, and water treatment.

Discrete control: Assembly lines, robot control, material handling.

Building Automation

HVAC (Heating, Ventilation, and Air Conditioning), lighting, and safety systems.

Other Industrial Scenarios

Medical equipment, testing instruments, transportation systems.

Installation and Maintenance

Installation Method

Can be installed on switchgear or control cabinets, supporting modular integration.

Maintenance Suggestions

Regular inspection: Clean the equipment, conduct function tests, and update software.

Fault recording: Use the fault recording module to record analog and digital data.

Training and guidelines: Follow the ABB maintenance manual, and operators need to receive the latest training.
