ABB UFC762AE101 3BHE006412R0101

ABB UFC762AE101 3BHE006412R0101 is a universal industrial controller designed for industrial automation systems, featuring high precision, reliability, and modularity. As a key component of ABB's automation systems, this module is widely applied in industrial process control, robot control, environmental monitoring, and other fields. It supports complex control logic and data acquisition, enhancing production efficiency and product quality.

Parameters

Electrical Parameters

Power Voltage: 100-240VAC (50/60Hz), 24VDC/AC±2V.

Power Consumption: ≤2W (for some models).

Input Signals: Analog inputs (0-5V, 0-1V, 4-20mA), digital inputs (ON/OFF).

Output Signals: Analog outputs (0-5V, 4-20mA), digital outputs (ON/OFF), relay contact switches (220VAC/2A or 24VDC/2A), SSR drive (12VDC/30mA).

Control Precision: ±0.2%F.S±1 digit, with automatic compensation for temperature and time drift.

Performance Parameters

Measurement Cycle: 0.5s.

Communication Interfaces: Supports Modbus, Profibus, and other protocols, RS485 communication.

Isolation Voltage: 1500V between input and output, 1000V between input/power and output/power.

Physical & Environmental Parameters

Dimensions: 100×112×45mm (some models) or 144×144×102mm.

Mounting Methods: DIN35 rail mounting, wall-mounted installation.

Protection Level: IP20 (some models support higher protection).

Operating Temperature: -10°C to +55°C (some models support -40°C to +70°C).

Relative Humidity: ≤80%RH (non-condensing).

Product Features

Modular Design: Facilitates installation, replacement, and upgrading, supports multi-axis control (e.g., servo motors) and extended analog input channels (e.g., 16 channels).

High Reliability: Uses industrial-grade components and supports safety functions such as overload protection, short-circuit protection, and overheat protection.

Programmability: Supports multiple programming languages to achieve complex control logic and secondary development.

Communication Functions: Compatible with various industrial protocols (Modbus, Profibus, RS232/485) for easy system integration.

High Protection Level: IP20 protection, suitable for dusty and humid conditions in industrial environments.

Structure & Composition

Core Components

Microprocessor: 32-bit RISC processor, 100 MHz clock speed, 256 KB memory, 2 MB program storage.

I/O Interfaces: 8 analog inputs, 8 switch inputs, 4 relay outputs, 8 power outputs (for sensors).

Communication Interfaces: Supports RS232, RS485, Ethernet, and other protocols; some models support USB/PCIe interfaces.

Expansion Capability

Supports multi-axis servo control and analog expansion modules, suitable for complex motion control scenarios.

Application Areas

Industrial Automation

Industrial process control, robot control, conveyor system control.

Energy Industry

Automation control and monitoring in power and petrochemical industries.

Infrastructure

Water treatment, sewage treatment, compressor control, etc.

Other Fields

Machinery manufacturing (textile, printing, packaging), 24V DC load devices such as LED light strips and cameras.

Installation & Maintenance

Mounting Methods

Rail Mounting: Fixed on DIN35 rail, suitable for standard control cabinets.

Wall-mounted Installation: Suitable for space-constrained scenarios.

Installation Notes

Environmental Requirements: Avoid high-temperature, humid, explosive, or corrosive environments; select the operating temperature range according to the specific model.

Power-off Operation: Disconnect the power supply before installation or debugging to prevent electric shock.

Maintenance Recommendations

Regular Inspection: Ensure wiring is secure and the protection level meets requirements to avoid failures due to looseness.

Manual Reference: Refer to the official product manual for detailed parameters and debugging steps.
