ABB 5SHY3545L0010 3BHB013088R0001 3BHE009681R0101 GVC750BE101ABB 5SHY3545L0010 3BHB013088R0001 3BHE009681R0101 GVC750BE101 are high-performance power semiconductor modules manufactured by ABB, which are widely used in fields such as industrial automation, power systems and High-Voltage Direct Current (HVDC) transmission. Among them:
5SHY3545L0010 and 3BHB013088R0001 are IGCT (Integrated Gate-Commutated Thyristor) modules, used in frequency converters, HVDC systems and pulse power supplies.
3BHE009681R0101 is an IGCT driver, used to drive the above-mentioned IGCT modules.
GVC750BE101 is an ABB frequency converter, suitable for pumps, fans, compressors and conveying systems.
Parameters
Voltage range: 240VDC (some models may be 260-120VDC)
Output current: 1mA
Operating temperature: -20℃ to 60℃ (some models are marked 1000℃, which may be an error)
Voltage range: 240VDC
Input current: 414mA
Operating temperature: -20℃ to 60℃
Voltage: 24V DC
Current: 10A
Operating temperature: -40℃ to +70℃
Input voltage: 110-240V AC
Output power: 750W
Operating temperature: -20℃ to 60℃
Product Features
High Performance and Reliability
Integrate GTO chips, anti-parallel diodes and gate drive circuits to achieve high integration.
Equipped with current and voltage limiting functions to ensure safe operation of the system.
Some models are equipped with overheating protection function to improve safety.
Communication and Compatibility
Provide communication interfaces, which can be integrated with other control systems to realize remote monitoring.
Compatible with ABB systems, suitable for various industrial automation scenarios.
Environmental Adaptability
Suitable for harsh industrial environments such as high temperature and high humidity.
The warranty period is usually 1 year (2 years for some models).
Structure and Composition
IGCT Modules (5SHY3545L0010, 3BHB013088R0001)
Core components:
GTO chip (Gate Turn-Off Thyristor).
Anti-parallel diode (for reverse current protection).
Gate drive circuit (to control IGCT switching).
Integrated design: single-chip packaging, reducing volume and cost.
Driver (3BHE009681R0101)
Provide precise gate trigger signals for IGCT modules to ensure efficient commutation.
Frequency Converter (GVC750BE101)
Include main control chip, power module and heat dissipation system, used to adjust motor speed.
Application Fields
Industrial Automation
Robot control, automated production lines, PLC/DCS systems.
Power Systems
High-Voltage Direct Current (HVDC) transmission, Static Var Compensator (SVC).
Energy and Manufacturing
Petrochemical industry, electronic manufacturing, automobile manufacturing, plastic machinery, etc.
General Equipment
Pumps, fans, compressors, conveying systems.
Installation and Maintenance
Installation Requirements
On-site installation: must be operated by professionals to ensure that electrical connections and grounding meet safety standards.
Environmental conditions: keep clean and dry, avoid dust and corrosive gases.
Maintenance Suggestions
Regular inspection: monitor temperature, current and voltage parameters to prevent overheating or overload.
Cleaning and lubrication: regularly clean radiators and contact points to ensure heat dissipation efficiency.
Spare parts replacement: provide a one-year warranty (two years for some models), and can respond quickly in case of emergency.
