ABB 5SHY3545L0016 3BHB020720R0002 3BHE019719R0101 GVC736BE101
ABB 5SHY3545L0016 is a key component in industrial automation systems produced by ABB, widely used in industrial scenarios requiring precise control and monitoring. It belongs to the SHY series and is designed to be integrated into larger automation systems, providing high-performance and high-reliability electrical control and protection functions. This product can be part of modular solutions, suitable for fields such as power generation, power distribution, manufacturing, and automation systems. Its core functions include overload protection, short-circuit protection, phase loss protection, etc., to ensure the safe operation of equipment.
Parameters
Basic Parameters
Model: 5SHY3545L0016
Manufacturer: ABB
Series: SHY series (some data mentions IGCT module or control module).
Electrical Parameters
Rated Voltage:
230/400V (motor protection relay);
220V (electrical products);
3500V/4500V (IGCT module).
Rated Current:
35A (motor protection relay);
16A (electrical products);
3500A/3600A (IGCT module).
Frequency Range: 50/60Hz (general).
Physical Parameters
Dimensions:
100mm × 50mm × 30mm (compact type);
45mm × 90mm × 75mm (motor protection relay);
330mm × 220mm × 120mm (IGCT module).
Weight:
150g (compact type);
0.35kg (motor protection relay);
20kg (IGCT module).
Protection Class: IP20 (some electrical products).
Operating Environment
Temperature Range: -25°C to +70°C (motor protection relay); -40°C to +150°C (IGCT module).
Product Features
High Performance and Reliability
Adopts advanced materials and processes, supporting high-voltage and large-current operation, suitable for harsh environments.
High precision and low power consumption (such as low on-state voltage drop).
Functional Characteristics
Protection Functions: overload, short circuit, phase loss, reverse phase, and leakage protection.
Control Capability: supports switching, sensing, and control functions to achieve efficient data processing.
Communication Interfaces: compatible with protocols such as Modbus, Profibus, and Ethernet.
Design Advantages
Compact Design: small size, easy to install and maintain.
Modularity: can be integrated into systems such as PLC and DCS, supporting scalability.
Long Service Life: high-quality materials and processes ensure long-term stable operation.
IV. Structure and Composition
Core Components
IGCT Module: integrates GTO chips, anti-parallel diodes, and gate drive circuits, connected through low inductance.
Control Module: includes input/output ports (such as 16-channel digital input/output), relay contacts (20 pieces), and a touch screen (7-inch color screen).
Power Module: 24V DC output, rated current 16A.
Installation Methods
Supports DIN rail or panel mounting.
Water-cooled heat dissipation design (IGCT module).
V. Application Fields
Industrial Automation
Used for input/output control in PLC and DCS systems.
Suitable for precision control scenarios such as robots and servo motors.
Power Systems
High-power drives (such as motor speed control systems).
Power conversion equipment such as high-voltage frequency converters and inverters.
Specific Industries
Industry: chemical industry, textile industry, food processing, etc.
Commercial and Residential: circuit protection, power distribution systems.
Agriculture: irrigation systems, agricultural machinery and equipment.
VI. Installation and Maintenance
Installation Steps
Environmental Requirements: ensure the installation location meets the IP protection class (such as IP20).
Wiring Specifications: follow standard industrial voltages (such as 230/400V) and currents (such as 16A/35A).
Safety Measures: operate after power off to avoid electric shock risks.
Maintenance Guidelines
Daily Inspection: regularly test protection functions (such as short-circuit and overload response).
Cleaning and Maintenance: keep heat dissipation channels unobstructed (such as the water-cooled system of the IGCT module).
Troubleshooting: refer to the official manual to handle abnormalities (such as contact wear, communication interruption).
Notes
Parameter Matching: select voltage and current levels according to actual needs (such as current differences between different models).
Spare Parts Management: prioritize the use of original accessories to avoid compatibility issues.
