ABB 5SHY35L4503 3BHB004693R0001 5SXE01-0127_Xiamen XingRuiJia Import and Export CO,LTD

Model：ABB 5SHY35L4503 3BHB004693R0001 5SXE01-0127

Brand: ABB
Price range (USD): 100-20000
Country: Switzerland
Parameter: Product Model: 5SHY35L4503
Input Voltage: 3 × 380–480 V AC
Input Frequency: 50/60 Hz
Output Voltage: 24 V DC
Output Current: 15 A
Power: 360 W
Dimensions: 140 x 80 x 160 mm
Weight: 1.7 kg
Protection Class: IP20
Operating Temperature Range: -10°C to +50°C
Installation Method: DIN rail (35 mm)

ABB 5SHY35L4503 3BHB004693R0001 3BHB004692R0002 5SXE01-0127

The ABB 5SHY35L4503 is a high-efficiency power supply module specifically designed for industrial automation, aiming to provide stable and reliable power supply for drive systems and control panels. As a core component of ABB's industrial automation solutions, this module ensures the continuous operation of automation equipment and reduces the risk of downtime through high-efficiency power conversion. Its design meets the stringent requirements of industrial environments and is suitable for complex control scenarios.

Parameters

Product Model: 5SHY35L4503
Input Voltage: 3 × 380–480 V AC
Input Frequency: 50/60 Hz
Output Voltage: 24 V DC
Output Current: 15 A
Power: 360 W
Dimensions: 140 x 80 x 160 mm
Weight: 1.7 kg
Protection Class: IP20
Operating Temperature Range: -10°C to +50°C
Installation Method: DIN rail (35 mm)

Product Features

High Efficiency: Conversion efficiency exceeds 94%, significantly reducing energy consumption and operating costs.
Reliability: Adopts a powder-coated metal housing with IP20 protection class, resisting dust, moisture, and electromagnetic interference.
Safety Protection: Built-in overload and short-circuit protection functions to prevent equipment damage caused by electrical faults.
Compact Design: Saves space and facilitates integration into both new and old systems.
Intelligent Monitoring: Equipped with LED indicators to display power status and fault information in real-time.
Compatibility: Seamlessly integrates with ABB's full range of automation products, supporting the efficient operation of complex control systems.

Structure and Composition

Housing: Powder-coated metal material, providing physical protection.
Circuit Board: Integrates core electronic components, including trigger circuits and heat dissipation modules.
Connectors: Support DIN rail installation, facilitating modular expansion.
Heat Dissipation System: Built-in heat sinks to ensure stable operation in high-temperature environments.
Protection Circuit: Multi-level protection mechanisms covering overvoltage, overcurrent, and short-circuit protection.

Application Fields

Industrial Automation: Provides stable power for PLC, I/O modules, sensors, etc.
Robotics Technology: Supports precise motion control and real-time response requirements.
Power Systems: Used in motor drives, grid management, and variable frequency speed regulation.
Energy Management: Optimizes equipment energy consumption and improves energy utilization efficiency.
Transportation: Applied to motor control and speed regulation of electric vehicles.
Building Automation: Integrated into building control systems to achieve efficient energy management.

Installation and Maintenance

Installation Requirements:

The control panel must meet the IP20 protection standard and reserve sufficient ventilation space.
The module is installed on a 35 mm DIN rail, with a spacing of at least 15 mm between adjacent modules to promote heat dissipation.
Grounding must comply with the IEC 61131-2 standard to reduce electrical noise interference.

Maintenance Recommendations:

Quarterly Inspection: Verify terminal connections and LED indicator status.
Cleaning: If corrosion is found, clean the terminal blocks with a damp cloth.
Troubleshooting: Replace the module in case of continuous faults.
Firmware Update: Perform through ABB engineering tools during non-production hours.

Warranty and Support

Provides a 24-month warranty against manufacturing defects and functional failures.
Global technical support covers remote diagnosis and on-site services.
