ABB 5SHY3545L0016 3BHB020720R0002 3BHE039203R0101 GVC736CE101
The ABB 5SHY3545L0016 3BHB020720R0002 is a high-performance industrial automation component manufactured by ABB, belonging to its industrial control system and automation product series. This model can function as a digital input module, controller, or IGCT module, with specific functions determined by the application scenario. It is designed to meet the requirements of high reliability and efficiency in industrial environments and is suitable for complex industrial automation systems.
Structure and Composition
Module Types
Digital input module: Equipped with 8 digital input channels, supporting discrete signal input, suitable for signal acquisition in industrial control systems.Controller: Adopts a modular design, integrating 32 control points (16 inputs / 16 outputs) and supporting the Modbus communication protocol.IGCT module: Combines the stable turn-off capability of transistors with the low-loss characteristics of thyristors, used in high-power switching and control applications.
Physical Characteristics
Dimensions: 100mm × 50mm × 30mm (controller module) or 580mm × 460mm × 460mm (industrial motor).Material: Cast aluminum alloy (motor) or industrial-grade materials (module).Protection class: IP55 (motor); modules generally comply with standards such as IEC 60947-5-1.
III. Parameters
Model: 5SHY3545L0016 3BHB020720R0002Type: Digital input module, controller, IGCT module (depending on specific application)Rated voltage: 24V DC (controller module) or 380V (industrial motor)Rated current: 35A (motor protection device) or 350A (IGCT module)Power: 100kW (IGCT module) or 45kW (industrial motor)Switching frequency: 2kHz (IGCT module) or 20kHz (IGCT module)Operating temperature: -40℃~85℃ (controller module) or -20℃~40℃ (motor)Cooling method: Water cooling (IGCT module) or natural cooling (motor)Protection class: IP55 (motor), modules usually have no protection class marking
IV. Product Features
High Performance
High efficiency, low noise, low vibration (motor);High switching frequency and low loss (IGCT module).
Reliability
Industrial-grade design, adapting to harsh environments (such as high temperature, high humidity);Long service life and anti-interference ability (digital input module).
Compatibility
Supports multiple communication protocols (such as Modbus);Suitable for various industrial scenarios (such as compressors, pumps, fans, etc.).
V. Application Fields
Industrial Automation
Used in production line control, robot control, PLC/DCS systems.
Power System
Transformer control, power regulation, high-power drives.
Specific Industries
Chemical industry, textile industry, food processing, pharmaceutical industry, metallurgy, intelligent transportation, etc.
VI. Installation and Maintenance
Installation
Modular design: Can be installed in racks or cabinets, wiring must follow standard specifications.Environmental requirements: Ensure good ventilation, avoid dust and corrosive gases.
Maintenance
Regularly check the wiring and connection status;Refer to ABB official documents for troubleshooting.
