ABB 5SHY4045L0003 3BHB021400 3BHE019719R0101 GVC736BE101
I. Overview
The ABB 5SHY4045L0003 3BHB021400 is an industrial electrical component belonging to ABB's electrical and automation product series. It is mainly used in the field of power distribution and control. This product is designed to meet the requirements of harsh industrial environments, featuring high reliability, advanced protection functions and modular design. Its core function is to achieve high-efficiency power control through IGCT (Integrated Gate-Commutated Thyristor) technology.
II. Parameters
Model and ManufacturerModel: 5SHY4045L0003 / 3BHB021400Manufacturer: ABB
Key ParametersRated voltage: 4.5kV (IGCT module)Rated current: 1200A (IGCT module)Maximum on-state voltage drop: 3.1V; Maximum off-state voltage drop: 5.0VInput voltage: Usually 24V DC (applicable to some modules)Output current: Varies by model, please refer to the product manualCommunication protocols: Supports Modbus, Profibus, etc.Operating temperature range: -40°C to +125°C (IGCT module); -20°C to 60°C (other modules)III. Product Features
High Reliability and ProtectionDesigned to handle high current loads and provide stable circuit protection.Possesses high voltage withstand capability, low conduction loss and fast switching characteristics.
Modular DesignAdopts a modular structure, facilitating installation and maintenance.Can be seamlessly integrated into ABB and other third-party PLC systems.
Energy Saving and High EfficiencyLow power consumption design (maximum on-state power consumption 4800W, maximum off-state power consumption 1500W).Supports precise control to reduce energy waste.
Environmental AdaptabilityCan operate stably in harsh environments with an IP55 protection rating.IV. Structure and Composition
Core ComponentsComposed of multiple Thyristors in a modular package.The IGCT module includes a four-layer PN junction structure, enabling high-speed switching and low loss.
Physical CharacteristicsCompact size and light weight, facilitating installation.Cooling method: Natural cooling (for some models).V. Application Fields
Industrial AutomationUsed for motor control and protection in machinery, metallurgy, chemical, textile and other industries.Supports PLC system integration to achieve automated control.
Energy ManagementRealizes precise current and voltage control in lighting systems and welding equipment.
High-Voltage Power ApplicationsSuitable for High-Voltage Direct Current (HVDC) transmission systems.
Other FieldsIndustrial machinery (such as fans, water pumps), ships, papermaking and other industries.VI. Installation and Maintenance
Installation RequirementsMust comply with standard installation specifications to ensure that the ambient temperature and humidity meet the requirements.The modular design simplifies the installation process and reduces downtime.
Maintenance RecommendationsRegularly inspect connecting components and heat dissipation systems to ensure long-term stable operation.Provides a one-year warranty period (for some models).
TroubleshootingMonitor parameter abnormalities through diagnostic tools and adjust or replace modules in a timely manner.
Xingruijia focuses on providing ABB industrial automation full range product services and your intelligent control solution partner
If you would like to learn more about our products and services, please feel free to contact us at any time!
