ABB SC510 3BSE003832R1
Overview
The ABB SC510 3BSE003832R1 is a submodule carrier produced by ABB, specifically designed for ABB Advant controllers (such as the Advant OCS system). It is used to install and connect other functional modules, thereby expanding the capabilities of the control system. It does not contain a CPU itself but achieves logical control, data processing, and communication functions by integrating different submodules (such as I/O modules and communication modules). This module is widely used in industrial automation, power systems, manufacturing, and other fields, supporting flexible configuration and expansion.
Parameters
Installation method: DIN rail mounting (some models may have standard cabinet dimensions).Operating temperature:-20℃ to 60℃ (typical value);-20°C to 55°C (some data);-40℃ to 85℃ (extreme range).
Note: Specific parameters are subject to official data, and there may be version differences.Protection class: IP20 (industrial-grade protection).Dimensions and weight:Dimensions: 115 x 65 x 23 mm (some models);Weight: approximately 0.24 kg (some models);Other models: 120 x 40 x 150 mm (weight 0.6 kg); 150 x 45 x 127 mm (weight 0.5 kg).Input voltage: 24V DC (some models).Communication interfaces: Supports protocols such as RS232, RS485, and Ethernet.
Product Features
Modular design:Provides flexible submodule slots (e.g., 4 slots) for easy function expansion according to needs.Standard interface design for easy connection with other modules.High reliability:Uses industrial-grade components and high-strength aluminum alloy materials to adapt to harsh environments.Complies with EMC Class 4 standards and integrates ±15KV ESD protection circuits.Compatibility:Specifically designed for the ABB Advant OCS system, compatible with various submodules (such as I/O and communication modules).Supports multiple programming languages and function libraries to achieve complex logical control.Easy installation and maintenance:DIN rail mounting simplifies the installation process.Provides remote diagnosis and maintenance functions to reduce maintenance costs.
Structure and Composition
Core components:Submodule slots: Used for installing I/O modules, communication modules, etc.Backplane connectors: Realize electrical connections between modules.Communication interfaces: Supports protocols such as RS232, RS485, and Ethernet.Safety design:Integrates safety switch status detection function to ensure the start/stop control of dangerous machines.Protection class IP20 to prevent dust and liquid intrusion.
Application Fields
Industrial automation:Production line control in manufacturing (automotive, electronics, food processing).Logical control of industrial robots and material handling systems.Power systems:Control of power distribution systems in power plants and substations.Power grid protection and monitoring systems.Process industry:Control of pumps, compressors, and other equipment in the petrochemical and pharmaceutical industries.Sensor signal processing in water treatment systems.Other fields:Shipbuilding, aviation manufacturing, mining, fire rescue, etc.
Installation and Maintenance
Installation steps:Fix the module using a DIN rail to ensure a secure installation.Connect power and communication cables according to the ABB official manual.Maintenance recommendations:Regularly check the operating status and communication connections.Follow the installation and maintenance manual provided by ABB to ensure safe and stable operation of the system.Provides 12-month warranty and after-sales support.
