ABB CI522A 3BSE018283R1_Xiamen XingRuiJia Import and Export CO,LTD

Model：ABB CI522A 3BSE018283R1

Brand: ABB
Price range (USD): 100-20000
Country: Switzerland
Parameter: Model: CI522A 3BSE018283R1
Input Voltage: 24V DC
Operating Temperature Range: -25°C to +70°C
Protection Class: IP20
Dimensions: 120mm x 40mm x 27mm
Weight: 0.2 kg
Communication Protocols: AF100 (main protocol), supporting PROFIBUS DP, Modbus, etc.
Transmission Rate: Up to 1Mbps (AF100 protocol)
Interface Types: RS232, RS485, Ethernet, PROFIBUS DP, etc.

ABB CI522A 3BSE018283R1

I. Overview

The ABB CI522A 3BSE018283R1 is an AF100 interface module, specifically designed for ABB's industrial automation systems. It is mainly used in the S800 I/O system and Advant OCS/S100 I/O system, providing redundant communication functions to ensure the stability and reliability of data transmission.

Product Series:
AC800M series PLC
Advant Controller 400 series
Advant OCS/S100 I/O system

Core Functions

It realizes communication with field devices through the AF100 protocol, supports analog signal input (0-20mA/0-10V) and digital signal processing, and is suitable for industrial control, process monitoring and other scenarios.

II. Parameters

Model: CI522A 3BSE018283R1
Input Voltage: 24V DC
Operating Temperature Range: -25°C to +70°C
Protection Class: IP20
Dimensions: 120mm x 40mm x 27mm
Weight: 0.2 kg
Communication Protocols: AF100 (main protocol), supporting PROFIBUS DP, Modbus, etc.
Transmission Rate: Up to 1Mbps (AF100 protocol)
Interface Types: RS232, RS485, Ethernet, PROFIBUS DP, etc.

III. Product Features

High Reliability and Stability

Adopts modular design, supports redundant communication, and enhances system reliability.
IP20 protection class, suitable for industrial environments.

Flexible Communication Capability

Supports AF100 protocol and is compatible with various industrial protocols (such as PROFIBUS DP, Modbus).
The maximum transmission rate can reach 1Mbps, meeting the needs of real-time data transmission.

Low Noise and High Precision

Input and output channel isolation design reduces noise interference.
Supports analog signal conversion (0-20mA/0-10V) with 12-bit resolution.

Easy Installation and Maintenance

Compact size, supporting DIN rail or screw mounting.
Built-in diagnostic function for easy troubleshooting.

IV. Structure and Composition

Core Components

Communication interface: Supports AF100, PROFIBUS DP, Ethernet and other protocols.
Signal processing module: Integrates analog/digital signal conversion circuit, supporting 0-20mA/0-10V input.
Power module: 24V DC input, output to the control system.

Connection Method

Fixed installation via DIN rail or screws.
Integrates with S800 I/O system or AC800M PLC to build a distributed control system.

V. Application Fields

Industrial Automation

Manufacturing, production line control, factory automation.

Process Control

Parameter monitoring and equipment control in chemical, petroleum and natural gas industries.

Power System

Monitoring and protection of power plants, substations and distribution systems.

Building and Transportation

HVAC, lighting system control; traffic signals, railway control systems.

Special Industries

Precise control of water treatment and food and beverage production lines.

VI. Installation and Maintenance

Installation Steps

Environmental requirements: Ensure the working temperature is within the range of -25°C to +70°C, and avoid humid or dusty environments.
Installation method: Use DIN rail or screws for fixing to ensure firmness.
Wiring specifications: Connect the power supply and signal lines strictly in accordance with the electrical drawings to avoid short circuits or reverse connections.

Maintenance Recommendations

Regular inspection: Check whether the connectors are loose and clean the surface dust.
Software update: Update the firmware through the ABB Ability™ platform to optimize performance.
Troubleshooting: Use the built-in diagnostic function to locate problems, and contact technical support if necessary.
