Model：ABB CS513 3BSE000435R1

Brand: ABB
Price range (USD): 100-20000
Country: Switzerland
Parameter: Model: CS513 3BSE000435R1
Brand: ABB
Operating Voltage: 24 V DC
Rated Current: maximum 2 A or 1.5 A
Rated Power: maximum 50 W
Communication Interfaces: Ethernet (RJ-45), RS-232, CAN, etc.
Communication Protocols: Modbus TCP/IP, Ethernet/IP, PROFIBUS DP, DeviceNet, etc.
Data Transmission Rate: 10/100 Mbps

ABB CS513 3BSE000435R1

The ABB CS513 3BSE000435R1 is an industrial automation module manufactured by ABB. It belongs to the S500 series or Advant Master control unit series, and is mainly used for communication expansion and data processing in industrial control systems. Its core function is to realize high-speed data exchange between industrial equipment and upper computers, HMI, PLC and other devices through Ethernet interface. It supports multiple industrial protocols (such as Modbus TCP/IP, PROFIBUS DP, DeviceNet, etc.) and is widely used in manufacturing, energy, building automation and other fields.

Parameters

Basic Parameters:

Model: CS513 3BSE000435R1
Brand: ABB
Operating Voltage: 24 V DC
Rated Current: maximum 2 A or 1.5 A
Rated Power: maximum 50 W
Communication Interfaces: Ethernet (RJ-45), RS-232, CAN, etc.
Communication Protocols: Modbus TCP/IP, Ethernet/IP, PROFIBUS DP, DeviceNet, etc.
Data Transmission Rate: 10/100 Mbps

Environmental Parameters:

Operating Temperature: -20°C to +60°C
Storage Temperature: -40°C to +85°C
Protection Class: IP20

Physical Specifications:

Dimensions:
Approximately 234 x 108 x 18 mm (DIN rail mounting type);
120 x 80 x 25 mm (compact type);
272 x 244 x 52 mm (robot controller module).
Weight:
Approximately 0.2 kg (compact type);
0.4 kg (DIN rail type);
3.5 kg (robot module).

Product Features

High Performance and Reliability:

Adopts high-performance processor and high-speed bus, supporting real-time data processing and rapid response.
Industrial-grade design with anti-interference capability, suitable for harsh environments.

Modularity and Compatibility:

Modular design, supporting DIN rail installation, facilitating expansion and maintenance.
Compatible with ABB Advant OCS, AC410, SG400 and other systems, supporting MasterBus 300E and IEEE 802.3 standards.

Usability and Security:

Provides user-friendly programming tools (such as IEC 61131-3, C/C++ support), simplifying configuration and fault diagnosis.
Built-in diagnostic function, which can monitor communication status in real-time and record error logs.

Multi-Protocol Support:

Supports multiple industrial protocols (such as Modbus TCP, PROFIBUS DP, DeviceNet) to meet the needs of different application scenarios.

Structure and Composition

Hardware Structure:

Core Components: 32-bit RISC processor, high-speed bus, multi-channel I/O interface.
Interface Types: Ethernet (RJ-45), serial communication (RS-232/CAN), relay output (N.C.).
Installation Methods: DIN rail mounting or plug-in module.

Software Functions:

Supports the programming environment of ABB Advant OCS system, providing rich function libraries and development tools.
Supports remote diagnosis and maintenance, reducing downtime.

Application Fields

Industrial Automation:

Used to connect PLC, HMI, frequency converters and other equipment to realize data exchange and remote monitoring.
Control the motion trajectory and operation of robots, machine tools and other equipment in manufacturing industry.

Process Control:

Monitor and control parameters such as temperature, pressure and flow in chemical, petroleum, natural gas and other industries.

Power and Energy:

Used for real-time data collection and equipment communication in thermal power plants, nuclear power plants and hydropower plants.

Construction and Transportation:

Control building air conditioning, lighting and security systems; manage traffic lights and monitoring systems.

Installation and Maintenance

Installation Steps:

Physical Installation: Fix the module through DIN rail or plug-in method to ensure good contact.
Electrical Connection: Wiring must comply with 24 V DC standards to avoid short circuits or overloads.
Network Configuration: Set parameters such as IP address and subnet mask to ensure communication with the upper computer.

Maintenance Suggestions:

Regular Inspection:
Check the shielding integrity of communication lines to avoid electromagnetic interference.
Run diagnostic tools regularly to monitor module operation status and error logs.
Troubleshooting:
Abnormal LED indicators need to be checked immediately and repaired with reference to the manual.
Back up system configurations and programs to prevent difficulties in accidental recovery.

Safety Precautions:

Avoid using in strong electromagnetic field environments to prevent signal interference.
Power off before replacing the module and follow ABB safety specifications.
