ABB DSAI133A 3BSE018290R1_Xiamen XingRuiJia Import and Export CO,LTD

Model：ABB DSAI133A 3BSE018290R1

Brand: ABB
Price range (USD): 100-20000
Country: Switzerland
Parameter: Model: DSAI133A 3BSE018290R1
Input Voltage: 24V DC ±20%
Input Current: Maximum 5 mA
Resolution: 16 bits
Number of Channels: 32 independently configurable analog input channels
Operating Temperature Range: -20°C to 60°C
Communication Protocol: PROFIBUS DP

ABB DSAI133A 3BSE018290R1

Basic Parameters

Model: DSAI133A 3BSE018290R1
Input Voltage: 24V DC ±20%
Input Current: Maximum 5 mA
Resolution: 16 bits
Number of Channels: 32 independently configurable analog input channels
Operating Temperature Range: -20°C to 60°C
Communication Protocol: PROFIBUS DP

Physical Specifications

Dimensions: Net depth 324 mm, net height 22.5 mm, net width 225 mm
Weight: 0.29 kg

Product Features

High Precision and Reliability

Equipped with a 16-bit A/D converter to ensure the accuracy of measurement data.
Internal self-calibration function reduces long-term operation errors.
Industrial-grade design with strong anti-interference capability and high stability.

Modularity and Flexibility

Modular design supports flexible configuration and can be combined with other modules to meet different application requirements.
Compatible with multiple signal types (voltage, current, thermocouple, RTD, etc.).

Ease of Use and Maintenance

Easy to install and maintain, suitable for control cabinets with limited space.
Provides electrical isolation to protect the module and system safety.

High Density and Compactness

Small size saves space, suitable for high-density I/O requirements.

Structure and Composition

Modular Structure: Includes input ports, signal conditioning circuits, A/D converter, isolation circuits, relay output ports, and communication interfaces.
Installation Method: DIN rail mounting (some documents mention IP20 rating, suitable for industrial environments).
Communication Interface: Supports PROFIBUS DP protocol and is compatible with ABB systems.

Application Fields

Industrial Automation

Widely used in process control systems in industries such as electric power, metallurgy, chemical engineering, and pharmaceuticals.
Used for monitoring and controlling analog signals such as temperature, pressure, and flow.

Control System Integration

Seamlessly integrates with PLC and DCS systems to achieve efficient data collection and control.

Special Scenarios

Monitoring and regulation of public utilities (e.g., electric power, water, natural gas).
Equipment status detection in discrete manufacturing.

Installation and Maintenance

Installation Requirements

Installed via DIN rail, ensuring the environment meets IP20 rating standards.
Operating temperature must be controlled within the range of -20°C to 60°C.

Maintenance Recommendations

Regularly inspect wiring and connectors to ensure good contact.
Clean the module surface to prevent dust and moisture from affecting performance.
Utilize the modular design to quickly replace faulty components, reducing downtime.
