ABB TU830V1 3BSE013234R1

1. Overview

The ABB TU830V1 3BSE013234R1 is a modular-designed extension module terminal unit for industrial automation systems, designed to connect various sensors and actuators while supporting analog and digital signal input/output. This module offers high reliability and flexibility to meet diverse industrial environment requirements.

-

2. Specifications

• Rated voltage: 50V
• Maximum current: 2A (per channel, max rated voltage: 50V)
• Signal channels: Supports up to 16 I/O channels, including two process voltage connections, two I/O connections, and one zero-point connection (ZP).
• Dimensions:
  • Depth/length: 64 mm
  • Height: 120.5 mm
  • Width: 110 mm
• Weight: 0.2 kg
• Operating temperature range: -40°C to +55°C
• Storage temperature range: -40°C to +85°C
• Humidity: 5% to 95% (non-condensing)

-

3. Key Features

• Modular design: Allows addition or removal of I/O modules to adapt to evolving production needs.
• High reliability: Built for harsh industrial environments, ensuring long-term stable operation.
• Flexibility: Compatible with multiple I/O modules and communication protocols for customizable control system configurations.
• Ease of use: Simple installation and configuration for quick deployment.
• Scalability: Supports diverse sensors and actuators for varied industrial applications.

-

4. Structure and Composition

• Module type: Extension Module Terminal Unit (MTU) with modular design for easy installation and expansion.
• Connection method: Field I/O modules are connected via terminal blocks, supporting modular expansion.
• Internal components: Includes multiple signal I/O channels for analog/digital signal transmission.

-

5. Applications

• Industrial automation: Widely used in automation systems to manage field sensors/actuators for analog/digital signal transmission.
• Control systems: Serves as a PLC system expansion module to enhance I/O module connectivity and system reliability.
• Environmental adaptability: Suitable for harsh conditions (e.g., high temperature, humidity) to ensure stable operation in industrial scenarios.
