Rated voltage: 220V-660V (AC/DC)

Rated current: 5A-2000A

Operating frequency: 50Hz/60Hz

Protection class: IP40

Communication interfaces: Modbus RTU/ASCII, IEC 61850, DNP3.0, SPA, Profibus, LON, etc.

Dimensions:

Version differences: Some data mention 96×96×144 mm, while others show 120×120×95 mm, which may vary depending on specific models or versions.

Operating temperature range: -20°C to +70°C; -25°C to +55°C

Storage temperature: -40°C to +70°C

Weight: Approximately 0.5 kg; 3.1-3.5 kg

Input/output: 4 analog input channels, 8 user-selectable switch input channels

Power supply: Supports 24-250V DC or 40-250V AC auxiliary power supply

Display: 2×16 LCD screen with multi-language interface

Thermal overload protection: Based on the IEC 60255 thermal model, supporting cold/hot curve memory to prevent motor damage due to overheating.

Short-circuit and earth fault protection: Provides single-phase, two-phase, or three-phase overcurrent protection and non-directional earth fault protection.

Fault recording module: Records fault status (up to 100 event codes + timestamps) and supports 4 analog inputs and 8 digital inputs.

Microprocessor technology: Continuously monitors hardware and software status and provides real-time alarms.

Multi-protocol compatibility: Supports protocols such as IEC 61850, Modbus, Profibus, and SPA, enabling seamless integration with DCS and SCADA systems.

Remote control: Communicates with the upper computer via optical fiber or RS-485 interface, supporting wireless or cable connections.

Plug-in design: Facilitates quick installation and replacement, reducing downtime.

Modular structure: Expandable functions to adapt to complex application scenarios.

Safety features: Short-circuit protection contacts and mechanical coding to prevent incorrect plugging.

Password protection: Users can set an HMI password to prevent misoperation.

Backup battery: Provides redundant power supply for the real-time clock to ensure data accuracy.

Core modules: Microprocessor unit, fault recording module, communication interfaces (optical fiber/RS-485).

Input/output terminals: X2.1-1 to X2.1-4 for phase current input, X4.1-1/2 for auxiliary power interface, and X4.1-3/4 for relay output contacts.

Enclosure: With IP40 protection class, supporting wall-mounted and rack-mounted installation.

Configuration tools: CAP 501/CAP 505 software for parameter setting.

Diagnostic function: The self-inspection system monitors the device status in real-time and provides fault early warning.

Manufacturing industry: Motor protection for key equipment such as pumps, fans, mills, and crushers.

Process industry: Application for high-load motors in petrochemical and metallurgical industries.

Grid substations: Protection for generators, transformers, and cable feeders.

New energy power generation: Suitable for motor control in distributed power sources such as wind energy and solar energy.

Marine and offshore: Certified by DNV, applicable to ships and offshore platforms.

Physical installation: Adopting a plug-in design, it can be directly inserted into the switchgear without additional wiring.

Wiring specifications: Refer to the terminal connection diagram in the technical manual (such as X2.1, X4.1, etc.).

Communication configuration: Select optical fiber or RS-485 module according to the protocol, and set the jumper position (plastic/glass optical fiber).

Regular inspection: Verify the linkage logic between the relay and the circuit breaker/contactor to ensure timely fault response.

Troubleshooting: Check the event log through the LCD screen to analyze the cause of the fault.

Cleaning and maintenance: Keep the interior of the device clean to avoid dust affecting heat dissipation.

Environmental requirements: Avoid high-temperature and high-humidity environments (humidity ≤95% without condensation).

Software update: Regularly update the firmware through CAP 501/CAP 505 tools to optimize performance.
