Product Introduction
The ABB MT-91-ARC FP A is an advanced arc fault protection module engineered to enhance electrical safety in industrial and commercial power systems. Designed with ABB’s proven protection technology, this unit provides rapid detection and mitigation of arc faults, significantly reducing the risk of equipment damage, fire hazards, and operational downtime. Its precision sensing and fast response make it a critical component in modern power distribution infrastructures.
Structure & Design
Built with a compact yet durable enclosure, the MT-91-ARC FP A integrates high-sensitivity arc detection sensors, a processing unit, and communication interfaces within a single module. The device is optimized for panel mounting and can be seamlessly incorporated into existing switchgear systems. Its internal architecture is designed to ensure electromagnetic compatibility and long-term operational stability.
Core Features
Ultra-Fast Arc Detection minimizes damage by responding within milliseconds
High Sensitivity Sensors capable of detecting light and current anomalies associated with arc faults
Reliable Protection Logic reduces false alarms while maintaining high safety standards
Flexible Integration compatible with ABB protection and control systems
LED Status Indicators provide clear visual feedback for operation and fault conditions
Compact Footprint ideal for installations with limited panel space
Typical Applications
The ABB MT-91-ARC FP A is widely applied in environments where electrical safety is critical, such as:
Medium- and low-voltage switchgear systems
Industrial manufacturing facilities
Power plants and substations
Data centers and critical infrastructure
Renewable energy installations (solar and wind systems)
Technical Details
The module is designed to meet demanding industrial requirements with stable and reliable performance. Key parameters include:
Model: MT-91-ARC FP A
Brand: ABB
Function: Arc Fault Protection
Power Supply: Typically 24V DC
Detection Method: Optical sensing combined with current monitoring
Response Time: Ultra-fast (milliseconds level)
Installation Type: Panel-mounted
Operating Temperature Range: -20°C to +60°C
Environmental Protection: Designed for industrial environments with high EMC resistance
Installation Guidelines
Installation should be carried out by qualified personnel to ensure proper system integration. The module should be mounted securely within the control panel and connected according to ABB’s wiring standards. Proper placement of arc sensors is essential to achieve optimal detection performance. It is also recommended to verify system configuration after installation to ensure correct operation.
Maintenance & Operation
The MT-91-ARC FP A requires minimal maintenance due to its solid-state design. However, periodic checks are recommended to ensure reliability:
Inspect sensor connections and cleanliness
Verify LED indicators for normal operation
Perform functional testing during scheduled maintenance cycles
Ensure firmware or system settings remain up to date if applicable
Additional Benefits
With its high-speed protection capability and dependable performance, the ABB MT-91-ARC FP A helps reduce maintenance costs, prevent catastrophic failures, and improve overall system safety. Its integration into electrical systems provides peace of mind and compliance with modern safety standards.
