Switzerland The ABB AI820 3BSE008544R1 is a high-performance analog input module from ABB’s S800 I/O series, designed for precise signal acquisition in distributed control systems (DCS). It supports multiple signal types and delivers reliable data conversion for industrial automation environments, ensuring stable monitoring and control of field processes.
| Parameter | Description |
|---|---|
| Model | AI820 3BSE008544R1 |
| Manufacturer | ABB |
| Product Type | Analog Input Module |
| Number of Channels | 4 |
| Input Types | Current & Voltage (bipolar differential) |
| Signal Range | ±20 mA, 0(4)…20 mA, ±10 V, 0(1)…5 V |
| Resolution | 14-bit + sign |
| Common Mode Voltage | Up to 50 V |
| Input Resistance | 250 Ω (current inputs) |
| Isolation | Group-isolated channels |
| Operating Temperature | -20°C to +60°C |
The AI820 module converts analog signals from sensors and transmitters into digital data that can be processed by control systems. Each of its four channels can independently handle voltage or current inputs, allowing flexible configuration in various industrial applications.
Additionally, the module distributes transmitter power directly to connected field devices, simplifying wiring and reducing the need for external power supplies.
The module is built with a rugged industrial PCB and high-quality electronic components to ensure long-term stability. Its compact form factor allows easy integration into ABB S800 I/O systems, while its isolation design protects against electrical interference and ensures reliable operation in noisy environments.
The ABB AI820 is widely used in industries requiring precise analog signal monitoring, including:
Power generation and energy systemsThe module is designed for seamless installation within ABB S800 I/O racks and is compatible with various Module Termination Units (MTUs). During installation:
Ensure proper wiring for voltage or current input selectionThe AI820 module is designed for low-maintenance operation, but regular checks are recommended:
Inspect wiring and terminal connectionsThe ABB AI820 3BSE008544R1 stands out for its flexibility, precision, and robustness. Its ability to support multiple signal types and provide reliable isolation makes it an essential component in modern distributed control systems, improving both operational efficiency and system safety.
