ABB UFC718AE101 HIEE3009936R0101
1. Overview
ABB UFC718AE101 HIEE3009936R0101 is a core component of ABB automation systems, designed specifically for industrial control systems, with high reliability and modular characteristics. Its core functions include processing control logic, data acquisition, and human-machine interaction, applicable to scenarios such as PLC (Programmable Logic Controller) and DCS (Distributed Control System). This product adopts the standard industrial bus PC104 structure, supports real-time embedded operating systems, and has multi-task processing capabilities. It is suitable for industrial fields such as petrochemicals, electric power, metallurgy, and papermaking, as well as the control of lighting, air conditioning, and ventilation systems in building automation.
2. Parameters
Processor: High-performance industrial-grade processor (the specific model is not clear, but the ARM Cortex-A9 dual-core 800MHz is mentioned).
Memory: 512MB RAM + 4GB eMMC flash memory.
Communication interfaces: 2 Ethernet ports (10/100M), 2 USB ports, 1 serial port, supporting protocols such as Modbus, Ethernet, Profibus, and CANopen.
I/O interfaces:
Digital input/output: 16 channels;
Analog input/output: 8 channels (supporting signals such as 0-10V, 4-20mA).
Power requirements: 24V DC or 48V DC input.
Operating temperature: -20℃ to +60℃ (some data mention -40℃ to 85℃, which may be due to version differences).
Protection level: IP20 (some data mention IP65, subject to the actual product).
Dimensions and weight: Approximately 220mm × 160mm × 80mm, weight about 2kg (some data mention smaller dimensions, which may be for different models).
3. Product Features
High reliability and stability: Adopting industrial-grade components and strict production processes, it can adapt to harsh industrial environments and has anti-interference capabilities.
Modular design: Supports flexible expansion, facilitating installation, maintenance, and upgrading.
Low power consumption and high integration: High-density circuit design, low heat generation, integrating multiple functions (such as multi-protocol communication, multi-channel I/O).
Programmability: Supports user-defined control logic and is compatible with ABB automation software tools (such as Control Builder).
Certifications and standards: Complies with the IEC 61131-3 standard and has passed safety certifications such as CE and UL.
4. Structure and Composition
Structure: Based on the standard industrial bus PC104 structure, adopting a modular design, facilitating integration with other industrial equipment.
Composition:
Core module: Includes processor, memory, communication interfaces, and I/O modules.
Expansion interface: Supports DIN rail mounting, providing digital/analog input/output, communication interfaces, etc.
Power management: Built-in power distribution function, supporting multi-module power supply.
5. Application Fields
Industrial automation:
PLC/DCS systems: Serve as core controllers to manage the logical control of production lines, robots, and other equipment.
Process control: Used for real-time data acquisition and process optimization in industries such as chemical engineering, petroleum, and electric power.
Building automation: Controls the operating status of systems such as lighting, air conditioning, and ventilation.
Critical infrastructure: Applied in scenarios requiring high reliability such as power grids and transportation, supporting redundant design and rapid fault response.
6. Installation and Maintenance
Installation requirements:
Ensure the working temperature is within the range of -20℃ to +60℃, avoiding high-temperature or humid environments.
Adopt DIN rail mounting, pay attention to grounding and lightning protection to prevent electrical interference.
Maintenance suggestions:
Regularly update the software to ensure system security and performance.
Check the connection status of communication interfaces and I/O modules to ensure stable signal transmission.
The modular design facilitates single-point fault detection and replacement, reducing maintenance costs.
