Parameter: Type: Analog Output Module
Signal Specification: AO: 4…20mA or 1…+5 VDC
Number of Channels: 16 independently configurable AO channels
Power Requirements: 24 VDC±10%, typical 100 mA, maximum 125 mA
Dimensions: Standard (190 mm)
Installation Method: Horizontal or vertical
Maximum Field Cable Length: 600 meters (1968 feet)
D/A Resolution: 12 bits
Accuracy: FSR±0.01%FSR, FSR=25 mA or 6.25 VDC
Other Features: Electrical isolation (1500 V, max. 1 minute), channel isolation (1×16 group isolation, 1500 V, max. 1 minute)12.
The AO02 is an analog output module from ABB, serving as a key component of the ABB Ability™ Symphony®Plus hardware system. This module is specifically designed to handle advanced analog output field signals and boasts various advanced features such as HART support, configurable output channels, and robust protection mechanisms.
Specifications:
Type: Analog Output Module Signal Specification: AO: 4…20mA or 1…+5 VDC Number of Channels: 16 independently configurable AO channels Power Requirements: 24 VDC±10%, typical 100 mA, maximum 125 mA Dimensions: Standard (190 mm) Installation Method: Horizontal or vertical Maximum Field Cable Length: 600 meters (1968 feet) D/A Resolution: 12 bits Accuracy: FSR±0.01%FSR, FSR=25 mA or 6.25 VDC Other Features: Electrical isolation (1500 V, max. 1 minute), channel isolation (1×16 group isolation, 1500 V, max. 1 minute)12.
Product Features
Circuit Breaker: High protection class (IP65), reliable arc-breaking technology, compact design for easy installation and maintenance.
Analog Output Module: High-precision D/A converter, channel isolation, HART protocol support, low noise, and fast update rate.
Digital Output Module: High switching capacity, optical isolation, LED status indication, DIN rail mounting design.
Safety Relay Module: Dual-channel redundancy, self-diagnosis functions (contact wear detection, power voltage monitoring), mechanical interlock structure.
Oxygen Sensor: Fast response, long lifespan, suitable for scenarios like vehicle exhaust detection.
Structure and Composition
Circuit Breaker: Compact structure, supports DIN rail or screw installation, convenient wiring.
Analog Output Module: Modular design with D/A converter, isolation circuit, power module, and hot-swap support.
Digital Output Module: Uses solid-state relays, integrates optical isolation and LED status indicators.
Analog Output Module: Industrial automation (e.g., robot control), process control (chemical, food processing), building automation (temperature, lighting control).
Digital Output Module: Pneumatic/hydraulic system control, motor/pump control, alarm signal generation, PLC external device connection.
